Video: The Best Wall We Know How to Make
Originally published by the following source: Applied Building Technology Group — January 30, 2019
by Timothy Ahrenholz
Picture this: you’ve been tagged to design the building envelope for the next national institution. Maybe it’s an addition to the Smithsonian, or a presidential library. In any case, you are building for posterity, and this thing has got to last. What do you do?
The so-called “institutional wall” is the choice for you! Start with a durable CMU wall, and protect it from erosion, moisture, and thermal cycling with continuous insulation, a water resistive barrier, an air barrier and a vapor retarder on the outer surface. Then guard those layers from UV, wind, and precipitation with cladding. While potentially more costly than alternative wall designs, this system provides the best long-term durability for important buildings. To better understand the building science at work behind this system, browse through the resources available at continuousinsulation.org. The website content is organized by user type, such as architect/engineer, building official, or builder/contractor.
A quick overview of the institutional wall is given in the following video, part of a series we are highlighting on effective wall design:
For additional information, please review the following articles, as well as the previous videos in this series:
